Orthotropic material

In material science and solid mechanics, orthotropic materials have material properties at a particular point which differ along three orthogonal axes, where each axis has twofold rotational symmetry. These directional differences in strength can be quantified with Hankinson's equation. They are a subset of anisotropic materials, because their properties change when measured from different directions. A familiar example of an orthotropic material is wood. In wood, one can define three mutually perpendicular directions at each point in which the properties are different. It is most stiff (and strong) along the grain (axial direction), because most cellulose fibrils are aligned that way. It is usually least stiff in the radial direction (between the growth rings), and is intermediate in the circumferential direction. This anisotropy was provided by evolution, as it best enables the tree to remain upright. Because the preferred coordinate system is cylindrical-polar, this type of orthotropy is also called polar orthotropy. Another example of an orthotropic material is sheet metal formed by squeezing thick sections of metal between heavy rollers. This flattens and stretches its grain structure. As a result, the material becomes anisotropic — its properties differ between the direction it was rolled in and each of the two transverse directions. This method is used to advantage in structural steel beams, and in aluminium aircraft skins. If orthotropic properties vary between points inside an object, it possesses both orthotropy and inhomogeneity. This suggests that orthotropy is the property of a point within an object rather than for the object as a whole (unless the object is homogeneous). The associated planes of symmetry are also defined for a small region around a point and do not necessarily have to be identical to the planes of symmetry of the whole object. Orthotropic materials are a subset of anisotropic materials; their properties depend on the direction in which they are measured.
